Operating Lever Horizontal, with Side Mounting

GN 820.2 Toggle Clamps, Steel, zinc plated

Toggle Clamps Steel zinc plated GN 820.2 thumbnail

Toggle Clamps Steel zinc plated GN 820.2 sketch

Type

MF	Forked clamping arm, with two flanged washers
MFC	Forked clamping arm, with two flanged washers and clamping screw GN 708.1

Show filter

Size	F_H in N Holding capacity	a ≈	b₁	b₂	b₃	d₁	d₂	h₁	h₂	h₃	h₄	h₅ max.

75	900	20	30	25,5	5,5	M 5	4,5	62	39	11	19	30
130	1000	32	39	35	6,5	M 6	5,5	85	57,5	16	25,5	47,5
230	1700	37	43	40	8,5	M 8	6,5	102	69	18	30	53
355	1800	58	52	52	10,5	M 10	8,5	135	92	22	37	73,5

Filter combination produces no result.

Size	l₁	l₂	l₃	l₄	m₁	m₂	m₃	r	s	w Adjustable range

75	118	30	72	45	18	13,5	6	42,5	2	15
130	170	45	95	55	26	22	6,5	61	2,5	17,5
230	195	52	113	68	28,5	24	8	70	3	20
355	270	85	166	77	32	32	10	108,5	3,5	19

Filter combination produces no result.

Specification

Steel

Case-hardened Steel C10
Zinc plated, blue passivated
Bearing pins tempered
Bearing rivets (for size 355 and up) case-hardened

All moving parts
Lubricated with special grease

Hand grip
High quality, oil resistant, red plastic

Clamping screw GN 708.1, type A

Steel, zinc plated
Rubber tip 85 Shore A

RoHS

Accessory

Clamping Screws

GN 801 Holders for Clamping Screws (for Type MF)

Clamping Arm Extenders GN 801.1 (for Type MF)

Clamping Arm Extenders GN 801.2 (for Type MF)

Information

Toggle clamps GN 820.2 work according to the toggle principle: lever and clamping bar move in the opposite direction.

They require less space for the clamping action. In the clamped position the operating lever is in its horizontal position. The 90° rotated mounting surface allows a space-saving installation in addition to the clamping point.

Toggle clamps in the U-bar version with two flanged washers (type MF) can accommodate an application specific clamping screw. A clamping screw with neoprene rubber tip is also included for type MFC.
