with Electrical Switching Function

GN 331 Tubular Handles

Type

T0	Without button
T1	With 1 button
T2	With 2 buttons

Identification no.

1	Without emergency stop
2	With emergency stop

Show filter

Length l ±0,25	d	b₁	b₂	h₁	h₂	t min.

200	M 8	27	17	51	68	15
300	M 8	27	17	51	68	15

Filter combination produces no result.

Specification

Handle tube Ø 30 x 1,5
Aluminum

Powder coated
Black, RAL 9005, textured finishSW
Anodized, natural colorEL

Handle legs zinc die casting
Powder coated
Black, RAL 9005, textured finish

Cover
(for version without emergency stop)
Plastic
Light gray

Temperature range: -25 °C to 55 °C

Load rating information

IP Protection Classes

RoHS

Accessory

Cables with connector coupling M12x1 GN 330

Information

Tubular handles GN 331 with electrical switching function are suitable for unlocking safety tumblers in rotating, detachable or side-sliding safety devices which must be closed in order to safeguard the required operational safety.

By integrating functions such as emergency stop, start, release, reset and LED status display, this tubular handle allows the machine to be monitored and operated directly at the door or gate.
