for Pulling Action
GN 851 Stainless Steel Latch Type Toggle Clamps
Type
| T2 | With square U-bolt, with catch |
| T | Without square U-bolt, with catch |
| Size | FH in N Holding capacity | a | b1 | b2 | b3 | b4 | b5 | d1 | d2 | h1 ≈ | h2 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 160 | 1600 | 12 | 26 | 28 | 21 | 20 | 14 | M 4 | 4,3 | 26 | 18 |
| 320 | 3200 | 16 | 40 | 44 | 32 | 28 | 22 | M 6 | 6,5 | 30 | 25 |
| 700 | 7000 | 24 | 60 | 54 | 38 | 38 | 26 | M 8 | 8,5 | 42 | 36 |
Filter combination produces no result.
| Size | l1 ≈ | l2 min. | m1 | m2 | m3 | m4 | m5 | r ≈ at w2 = 0 | s | w1 Stroke | w2 ≈ Adjustable range |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 160 | 98 | 11 | 19 | 5 | 16 | 5 | 10 | 35 | 2 | 25 | 11 |
| 320 | 152 | 19 | 32 | 10,5 | 19 | 7 | 14,3 | 54 | 3 | 48 | 13 |
| 700 | 220 | 21 | 38 | 9,5 | 41,5 | 9,5 | 19 | 70 | 3,5 | 58 | 26 |
Filter combination produces no result.
Specification
Stainless steelNI
All moving parts
Lubricated with special grease
Handle with plastic sleeve
red, oil resistant
RoHS
- Sheet metal parts / Square U-bolt
AISI 304 - Pin
AISI 303
All moving parts
Lubricated with special grease
Handle with plastic sleeve
red, oil resistant
RoHS
Information
The stroke of the square U-bolts of stainless steel latch type toggle clamps GN 851 can be adjusted within its range.
In the clamped position the square U-bolt is parallel to the fixing plane of the latch type toggle clamp.
In addition to the standard lengths for the U-bolt latch shown above, more lengths may be achieved by using square U-bolts GN 951.1.
see also...
| How to order |
| ||||||
GN 851-160-T2-NI |
