made of Antibacterial Plastic
GN 676 Knurled Knobs

d1 | d2 | d3 | h1 | h2 | t min. |
---|---|---|---|---|---|
21 | M 5 | 12,5 | 18 | 10,5 | 10 |
31 | M 8 | 18,5 | 27 | 17 | 15 |
Filter combination produces no result.
Specification
Plastic
Technopolymer (Polyamide PA)
Threaded bushing
Stainless steel AISI 303
RoHS
Technopolymer (Polyamide PA)
- Glass fiber reinforced
- Temperature resistant up to 130 °C
- Black-gray, RAL 7021, matte finishSGA
- White, RAL 9016, matte finishWSA
Threaded bushing
Stainless steel AISI 303
RoHS
Information
Knurled knobs GN 676 are manufactured from an antibacterial plastic.
Adding a silver-based substance has created a natural active agent that helps to prevent the growth of bacteria. Even after repeated cleaning with soap or solvent, the antibacterial effect of this additive will not diminish. Sterilising at temperatures below 130 °C will also have no effect on the antibacterial property.
With these properties, the handles are the perfect choice for use in medical engineering, in the food and the pharmaceutical industry, and in general wherever hygiene is of great importance.
see also...
How to order |
| ||||||
GN 676-31-M8-SGA |
