Zinc Die Casting, Threaded Stud Stainless Steel

GN 602.1 Adjustable Hand Levers

Adjustable Hand Levers GN 602.1 thumbnail

ELESA original design ERM.SST-p Info

Show filter

l₁	d₁			l₂							d₂	d₃	h₁	h₂	h₃	h₄ Stroke

44	M 4	-	-	12	16	20	25	32	-	-	10	14,5	24,5	3,5	30	3,5
44	M 5	M 6	-	12	16	20	25	32	40	50	10	14,5	24,5	3,5	30	3,5
63	M 6	M 8	-	16	20	25	32	40	50	63	13,5	18	31	3,5	38	4
78	M 8	M 10	M 12	20	25	32	40	50	63	80	16	21,5	36	3,5	46	4
95	M 10	M 12	-	20	25	32	40	50	63	80	19	25	43	5	56	4

Filter combination produces no result.

Specification

Handle
Zinc die casting

Powder coated
Black, RAL 9005, textured finishSW

Orange, RAL 2004, textured finishOS

Red, RAL 3000, textured finishRS

Silver, RAL 9006, textured finishSR

Threaded stud and retaining screw
Stainless steel AISI 303

Stainless Steel Characteristics

RoHS

Information

Adjustable hand levers GN 602.1 like all the products of the Ergostyle® family are renowned for their good style but also their ergonomical shape.

The gently arched handle with a reinforced end of the lever gives the operator a good grip.

Pulling the lever disengages the serration and allows it to be turned in either direction to reach the ideal new location. On releasing the handle the serrations re-engage automatically.
