Antibacterial Plastic

GN 628.1 Cabinet U-Handles, assembling from the operator's side

Cabinet U Handles assembling from the operators side GN 628.1 thumbnail

ELESA Original design EBP.SAN Info

Cabinet U Handles assembling from the operators side GN 628.1 sketch

Type

B	Mounting from the operator's side

Show filter

l₁	d₁	d₂	h₁	h₂	l₂	l₃ min.	s	sw	t

117 ±0,5	8,5	26	39	18	143	91	8,5	13	8,5
179 ±1	8,5	29	51	19	208	150	9,5	13	16

Filter combination produces no result.

Specification

Plastic
Technopolymer (Polyamide PA)

Glass fiber reinforced
Temperature resistant up to 130 °C
Black-gray, RAL 7021, matte finishSGA
White, RAL 9016, matte finishWSA

Cover cap
Plastic

Black-gray for SGA
White for WSA

Highlights - Sanline

Strength properties

Plastic Characteristics

RoHS

Information

Cabinet U-handles GN 628.1 are manufactured from an antibacterial plastic.

Adding a silver-based substance has created a natural active agent that helps to prevent the growth of bacteria. Even after repeated cleaning with soap or solvent, the antibacterial effect of this additive will not diminish. Sterilising at temperatures below 130 °C will also have no effect on the antibacterial property.

With these properties, the handles are the perfect choice for use in medical engineering, in the food and the pharmaceutical industry, and in general wherever hygiene is of great importance.
