with Cover Cap
GN 675.1 Softline Ball Handles, plastic, lagged with a soft elastomer
ELESA original EBK-C SOFT
| d1 | d2 | d3 | d4 | h1 | h2 ≈ | t | FDA | ||
|---|---|---|---|---|---|---|---|---|---|
| 43 | M 8 | M 10 | - | 32,5 | 20 | 53,5 | 17,5 | 18 | Ja |
| 50 | M 8 | M 10 | M 12 | 37 | 25 | 60 | 20 | 26 | |
Filter combination produces no result.
Specification
Base body
Plastic
Technopolymer (Polypropylen PP)
Softline coating
Bushing
Brass
Color of the cover cap:
TransparentDTR
Orange, RAL 2004, matte finishDOR
Gray, RAL 7035, matte finishDGR
Yellow, RAL 1021, matte finishDGB
Blue, RAL 5024, matte finishDBL
Red, RAL 3000, matte finishDRT
Green, RAL 6017, matte finishDGN
RoHS
Plastic
Technopolymer (Polypropylen PP)
Softline coating
- Elastomer (TPE) 70 Shore A
- Chemically bonded with base body
- FDA compliant plastic granulate
- Temperature resistant up to 80 °C
- Black, matte
Bushing
Brass
Color of the cover cap:
TransparentDTR
Orange, RAL 2004, matte finishDOR
Gray, RAL 7035, matte finishDGR
Yellow, RAL 1021, matte finishDGB
Blue, RAL 5024, matte finishDBL
Red, RAL 3000, matte finishDRT
Green, RAL 6017, matte finishDGN
RoHS
Accessory
Positioning and control symbols GN 517.1Information
The design of the ball handles GN 675.1 matches the product family Ergostyle®. The softline coating makes the control knobs particularly user-friendly and ergonomic.
The soft, slip-proof contact area improves the contact both in hot (hand perspiration) and in dry ambient conditions, in the event of oily surfaces and even high or low temperatures.
The softline ball handles are suitable for use both as operating elements and for clamping. The „hard" plastic core guarantees the perfect anchoring engagement of the threaded bushing, also under heavier loads.
The transparent cover cap allows symbols to be placed underneath.
Positioning and control symbols are to be ordered separately.
see also...
| How to order |
| ||||||
GN 675.1-50-M8-DGR |
RoHS compliant:
-
-
