with Vibration Damping, with Threaded Stud
GN 342.2 Leveling Feet
Type
| SV | With damping element |
| d1 | d2 | l1 | d3 | l2 | l3 | l4 Compression in N/mm² 0 | 0,4 | 0,6 | A/F | Area dampening element in mm² | Load in N by compression 0,4 N/mm² (see information) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 32 | M 10 | 50 | 80 | 30 | 29 | 11 | 5,5 | 3,8 | 2,7 | 15 | 707 | 280 |
| 40 | M 12 | 63 | 100 | 38 | 30 | 9,5 | 6 | 4,3 | 3,3 | 17 | 1134 | 450 |
| 50 | M 12 | 63 | 100 | 48 | 30,5 | 9 | 6,5 | 4,9 | 3,9 | 17 | 1809 | 720 |
| 60 | M 16 | 80 | 125 | 58 | 37,5 | 10 | 7 | 5,5 | 4,4 | 24 | 2641 | 1050 |
Filter combination produces no result.
Specification
Steel
Damping element
Elastomer (PUR)
Hexagon nut ISO 4032
Steel zinc plated, blue passivated
RoHS
- Property class 5.8
- Zinc plated, blue passivated
Damping element
Elastomer (PUR)
- Sylomer SR 450-12
- Anti-slip, glued
- Gray
- Oil resistant
- Operating range from -30 °C up to +70 °C
Hexagon nut ISO 4032
Steel zinc plated, blue passivated
RoHS
Information
The specified load in the above table is a recommendation up to which the damping insert can be permanently subjected.
This static load equals a thrust on the area of 0,4 N/mm2, at which the damping material reaches its optimum dynamic damping ability. This also takes into account an additional load up to 0,6 N/mm2 in the event of a dynamic load.
Leveling feet GN 342.2 cannot be disassembled.
see also...
| How to order |
| ||||||||
GN 342.2-50-M12-63-SV |
