with Ball Knob / with Key Ring, with Rubber Jacket
GN 51.7 Magnets
Type
| A | with knob |
| B | with key ring |
| d1 | d2 | d3 | h1 | h2 | h3 | Nominal magnetic forces in N |
|---|---|---|---|---|---|---|
| 22 | 16 | 20 | 6 | 25 | 13 | 35 |
| 31 | 16 | 25 | 6 | 25 | 14,5 | 75 |
| 43 | 16 | 30 | 5,5 | 24 | 17 | 85 |
Filter combination produces no result.
Specification
Steel part
Nickel plated
Material of the magnet
NdFeBND
Neodymium, iron, boron
Temperature resistant up to 80 °C
Rubber jacket
Elastomer (TPE)
80 Shore A ≈
Black
Ball knob
Plastic
Technopolymer (Polyamide PA)
Black, matte finish
Key ring
Steel, nickel plated
RoHS
Nickel plated
Material of the magnet
NdFeBND
Neodymium, iron, boron
Temperature resistant up to 80 °C
Rubber jacket
Elastomer (TPE)
80 Shore A ≈
Black
Ball knob
Plastic
Technopolymer (Polyamide PA)
Black, matte finish
Key ring
Steel, nickel plated
RoHS
Accessory
Holding Disks GN 70Adhesive Disks GN 70.1
Information
Magnets GN 51.7 with rubber jacket form a system together with the steel part that shields and strengthens the magnet, optimally concentrating the magnetic flux on the rubberized magnetic surface.
The rubber protects sensitive surfaces from being damaged by the magnet and also delivers a high friction coefficient, resulting in high lateral displacement forces.
see also...
| How to order |
| ||||||
GN 51.7-ND-31-A |
