Stainless Steel

GN 452 Buffers

Type

E	With internal thread
S	With threaded stud

Show filter

d₁	h Type E				Type S				d₂	Length l	s	t

8	8	13	-	-	8	13	-	-	M 3	6	1	3
10	10	15	-	-	10	15	20	-	M 4	10	1,2	4
15	15	20	-	-	10	15	20	30	M 4	10	1,4	4
20	15	20	25	-	10	15	20	30	M 6	18	2	6
25	15	20	30	-	15	20	30	-	M 6	18	2	6
30	15	20	30	40	15	20	25	30	M 8	20	2	8
40	20	30	40	-	20	25	30	40	M 8	23	2	8
50	20	30	40	50	20	30	40	50	M 10	28	2	8
60	30	40	50	-	20	40	60	-	M 10	28	2	8
70	30	40	55	-	30	40	55	-	M 10	27	3	8
75	30	40	50	-	25	40	50	-	M 12	37	3	11
100	40	50	60	-	40	50	60	-	M 16	41	3	14
125	55	75	-	-	55	75	-	-	M 16	41	3	14

Filter combination produces no result.

** not available from stock, requires a minimum order quantity

Specification

Natural rubber (NR)

Vulcanized to the cover plates
Temperature resistant up to 80 °C
Hardness Shore A ±5
Soft*40
Medium55
Hard*70

Cover plates, threaded bushings, threaded studs
Stainless Steel AISI 304

Elastomer Characteristics

Stainless Steel Characteristics

RoHS

On request

Rubber in gray

Information

Buffers GN 452 are used as end-stop buffers, e.g. for conveyor trolleys.

They absorb most of the kinetic energy developing on impact. They act as dampers and prevent damaging shock and rebound. They also act as sound dampers.
