Eccentrical cams GN 918.5 allow the rapid and safe clamping and releasing at a relatively large adjustable range and with high clamping force. The cam not only has the advantage that the clamping effect is of the same magnitude over the whole of the clamping surface (i.e. in every angular position), but also that it is self-arresting in every position.

The ball levers of types KV and GV feature a form-locking connection with the eccentrical cam by means of a serrated ratchet. During installation, this allows the lever to be fixed in a clamped position that is conveniently oriented with respect to the eccentrical cam.

Screw bolt and washer (see technical instructions) are matched to ensure that the eccentric cam can be easily turned after tightening. Using a washer requires no special requirements in terms of the threaded hole design. This means it can also be mounted on tables using T grooves.
