Plastic, Cover Cap Colored
GN 534 Knurled Knobs , bushing brass
ELESA original design MBT.
| d1 Nominal dimension | Actual dimension | d2 Thread | d3 H9 Bore | d4 | h1 | h2 | t1 min. | t2 min. |
|---|---|---|---|---|---|---|---|---|
| 32 | 31 | M 5 | - | 15 | 24 | 11,5 | 10 | - |
| 32 | 31 | M 6 | - | 15 | 24 | 11,5 | 12 | - |
| 40 | 39,5 | M 6 | B 6 | 17 | 26,5 | 12,5 | 12 | 14 |
| 40 | 39,5 | M 8 | - | 17 | 26,5 | 12,5 | 13 | - |
| 50 | 50 | M 8 | B 8 | 20 | 33 | 16 | 20 | 20 |
| 50 | 50 | M 10 | - | 20 | 33 | 16 | 18 | - |
| 60 | 61 | M 10 | B 10 | 23 | 39 | 18,5 | 20 | 25 |
| 60 | 61 | M 12 | - | 23 | 39 | 18,5 | 20 | - |
| 70 | 70 | M 12 | - | 24 | 42 | 20,5 | 20 | - |
| 70 | 70 | M 14 | - | 24 | 42 | 20,5 | 20 | - |
Filter combination produces no result.
Specification
Plastic
Technopolymer (Polypropylene PP)
Bushing
Brass
Color of the cover cap
Orange, RAL 2004, matte finishDOR
Gray, RAL 7035, matte finishDGR
Yellow, RAL 1021, matte finishDGB
Blue, RAL 5024, matte finishDBL
Red, RAL 3000, matte finishDRT
Green, RAL 6017, matte finishDGN
RoHS
Technopolymer (Polypropylene PP)
- Reinforced, shock-resistant
- Temperature resistant up to 90 °C
- Black, RAL 9005, matte finishSW
Bushing
Brass
Color of the cover cap
Orange, RAL 2004, matte finishDOR
Gray, RAL 7035, matte finishDGR
Yellow, RAL 1021, matte finishDGB
Blue, RAL 5024, matte finishDBL
Red, RAL 3000, matte finishDRT
Green, RAL 6017, matte finishDGN
RoHS
Information
The unique profileon the rim (small squares) of the knurled knobs GN 534 is characteristic of its form and the function.
| How to order |
| ||||||||
GN 534-50-M10-SW-DRT |
