Spindle Steel, Zinc plated
GN 598 Revolving Handles, plastic / steel
| d1 | d2 Plastic KU | KT | Steel ST | d3 | d4 | l1 | l2 | l3 | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 14 | - | - | M 6 | - | - | - | 8 | 11 | 28 | 10 | 0,5 |
| 18 | M 6 | - | M 6 | - | M 6 | - | 10 | 15 | 40 | 12 | 2,5 |
| 21 | M 6 | M 8 | M 6 | M 8 | M 6 | M 8 | 10 | 17 | 50 | 13 | 2,5 |
| 22 | M 6 | M 8 | M 6 | M 8 | - | - | 10 | 18 | 56 | 13 | 2,5 |
| 23 | M 8 | M 10 | M 8 | M 10 | M 8 | M 10 | 13 | 19 | 65 | 14 | 2,5 |
| 26 | M 8 | M 10 | M 8 | M 10 | M 8 | M 10 | 13 | 21 | 80 | 16 | 2,5 |
| 28 | M 10 | - | M 10 | - | M 10 | - | 13 | 22 | 90 | 16 | 2,5 |
| 31 | M 12 | - | - | - | M 12 | - | 14 | 25 | 102 | 20 | 2,5 |
Filter combination produces no result.
Specification
PlasticKU
Duroplast (Phenolic PF)
PlasticKT
Technopolymer (Polypropylene PP)
SteelST
Powder coated
Black, textured finish
Spindle
Steel
Zinc plated, blue passivated
RoHS
Duroplast (Phenolic PF)
- Temperature resistant up to 110 °C
- Black, shiny finish
PlasticKT
Technopolymer (Polypropylene PP)
- Temperature resistant up to 80 °C
- Black, matte
- Black, shiny finish (only size 14)
SteelST
Powder coated
Black, textured finish
Spindle
Steel
Zinc plated, blue passivated
RoHS
On request
With inch threads
Information
Steel revolving handles GN 598 are mainly used on safety handwheels to increase imbalance and thus avoid free wheeling.
| How to order |
| ||||||
GN 598-KU-21-M8 |
