with Clamping Hub

GN 2242 Oldham Couplings

Bore code

B	Without keyway
K	With keyway (from d°°1°° = 20)

Show filter

d₁	d₂ - d₃ H8 recommended shaft tolerance h7

12	4-4	4-5	5-5	-	-	-
15	4-4	4-5	4-6	5-5	5-6	6-6
20	6-6	6-8	6-10	8-8	8-10	10-10
30	8-8	8-10	8-12	10-10	10-12	12-12
38	12-12	12-15	12-20	15-15	15-20	20-20

Filter combination produces no result.

d₁	d₄	d₅	l₁	l₂ recommended shaft insertion depth	l₃	l₄

12	M 2	5,2	19	6,2	3,1	4
15	M 2,5	8,2	21,2	7	3,5	5
20	M 3	12,2	27	8,8	4,4	7,5
30	M 4	16,2	32,5	10	5	11,1
38	M 5	20,3	40	12,1	6	14,2

Filter combination produces no result.

Specification

Hub
AluminumAL
Anodized, natural color

Spacer
Plastic (Polyacetal POM)KU
Temperature resistant up to 80 °C

Socket cap screws DIN 912
Steel, blackened

Temperature range: -20 °C up to +80 °C

Highlights - Couplings

Keyway P9 DIN 6885

ISO Fundamental Tolerances

Plastic Characteristics

RoHS

Information

Oldham couplings GN 2242 can compensate for large lateral shaft misalignments while transmitting high torques. As a result, they are used in applications with a focus on pure torque and power transmission associated with high lateral shaft misalignments.

The clamping hubs and simple plug-in installation make oldham couplings very easy to assemble. They are suitable for a diverse range of applications and are used in general machine construction in packaging machines and pumps.

With the bore code K, the keyway is always integrated into both bores d₂ and d₃.
