Push to Engage
GN 312 Safety Tension Levers, with inner tread
Type
| E | Angled lever |
| D | Straight lever |
| d1 | d2 Thread | d3 | d4 | d5 | h1 | h2 | h3 | h4 Type E | Type D | h5 Stroke | l2 Type E | Type D | l3 | t min. | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 21 | M 6 | M 8 | 13,5 | 8 | 20 | 37 | 34,5 | 4,5 | 62 | 39 | 3 | 75 | 81 | 70 | 11 |
| 24 | M 8 | M 10 | 16 | 10 | 25 | 44 | 41 | 6,5 | 78 | 47 | 3,5 | 101 | 108 | 96 | 14 |
| 28 | M 10 | M 12 | 19 | 12 | 30 | 53 | 49 | 8,5 | 93 | 56 | 4 | 116 | 124 | 110 | 17 |
| 33 | M 12 | M 16 | 23 | 12 | 32 | 60 | 56 | 10,5 | 105 | 65 | 4,5 | 131 | 140,5 | 124 | 22 |
Filter combination produces no result.
Specification
Steel
Blackened
Ball knobs DIN 319
Plastic, Duroplast
Black, shiny finish
RoHS
Blackened
Ball knobs DIN 319
Plastic, Duroplast
Black, shiny finish
RoHS
On request
With inch threads
Information
Safety tension levers GN 312 are used on such applications where a thoughtless or mistaken releasing or re-positioning of the tension lever could lead to an accident.
The lever in its rest position is not connected with the internal spindle and can be rotated unhindered.
The tension lever engages in the serration only after pushing it down, thus allowing clamping or unclamping.
The "freewheel" position is re-established as soon as the handle is released.
| How to order |
| ||||||
GN 312-21-M8-E |
RoHS compliant:
-
-
