Cast Iron, Zinc Plated, Blue Passivated
DIN 6335 Hand Knobs
Type
| D | With threaded through bore |
| E | With threaded blind bore |
| d1 | d2 | d4 | h1 | h2 | t1 min. | t2 |
|---|---|---|---|---|---|---|
| 32 | M 6 | 12 | 20 | 9 | 12 | 10 |
| 40 | M 8 | 14 | 25 | 13 | 15 | 13 |
| 50 | M 10 | 18 | 32 | 18 | 18 | 16 |
| 63 | M 12 | 20 | 40 | 23 | 22 | 20 |
| 80 | M 16 | 25 | 50 | 28 | 28 | 20 |
Filter combination produces no result.
Specification
Cast ironGG
RoHS
- Zinc plated, blue passivatedZB
- Thread: screw mobility
RoHS
On request
Powder coated
Information
| How to order |
| ||||||||||
DIN 6335-GG-63-M12-D-ZB |
