for Mounting Clamps
GN 480.1 Stainless Steel Retaining Rods / Retaining Tubes
Type
| LS | With scale (mm-graduation) |
| OS | Without scale |
| d1 Diameter | Length l | k | d2 | ||||||
|---|---|---|---|---|---|---|---|---|---|
| D 8 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 15 | - |
| D 10 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 15 | - |
| D 12 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 15 | 9 |
| D 15 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 20 | 12 |
| D 16 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 20 | 13 |
| D 20 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 25 | 16 |
Filter combination produces no result.
Specification
Retaining rods / tubes, round
Stainless steelNI AISI 304
Ground
Longitudinal scale engraved
in laser precision
RoHS
Stainless steelNI AISI 304
Ground
Longitudinal scale engraved
in laser precision
RoHS
On request
Special scales
Information
The outside dimensions of retaining rods / retaining tubes GN 480.1 are matched for use with mounting clamps.
The retaining tubes can also be used as cable lead-through.
| How to order |
| ||||||||
GN 480.1-D10-150-NI-LS |
