with Rubber Thrust Pad
GN 708.1 Clamping Screws, Steel, zinc plated
Type
| A | Flat spindle tip |
| B | Rounded spindle tip |
| d1 | Length l | d2 | d3 | h | m | r | ||
|---|---|---|---|---|---|---|---|---|
| M 4 | 23 | 30 | - | 8 | 9,8 | 5 | 2,2 | 6 |
| M 4 | 33 | 43 | - | 8 | 8 | 10 | 2,2 | 6 |
| M 5 | 45 | 55 | - | 10 | 9 | 11 | 2,7 | 8 |
| M 6 | 35 | 55 | 65 | 13 | 12 | 12 | 3,2 | 10 |
| M 8 | 43 | 68 | - | 16 | 14 | 18 | 4 | 12 |
| M 10 | 50 | 77 | 97 | 20 | 18 | 21 | 5 | 15 |
| M 12 | 100 | 130 | - | 25 | 23 | 24 | 6 | 18 |
Filter combination produces no result.
Specification
Screw
Hexagon nuts ISO 4035
Thrust pad
Rubber, Neoprene (CR)
RoHS
- SteelST
Zinc plated, blue passivated
Hexagon nuts ISO 4035
- Steel
Zinc plated, blue passivated
Thrust pad
Rubber, Neoprene (CR)
- 85 Shore A ≈
- Vulcanized
- Black
RoHS
Information
The two hexagon nuts are included parts of the order.
| How to order |
| ||||||||
GN 708.1-M8-43-B-ST |
