GN 928 Shaft Clamping Units "Trueround"

Shaft Clamping Units Trueround GN 928 thumbnail

Shaft Clamping Units Trueround GN 928 sketch

Show filter

d₁ h11	d₂	d₃ Round workpiece	d₄ H7	d₅	e +0,2	l₁ max.	l₂	l₃	A/F	Max. tightening torque in Nm	Code No. Mounting tool

8	M 4	6 - 10	8	M 2,5	d₃ / 2 + 2,8	22	8	4	3	2,9	GN 928.1-3
10	M 5	10 - 15	10	M 3	d₃ / 2 + 3,3	30	10	5	4	6	GN 928.1-4
12	M 6	15 - 20	12	M 4	d₃ / 2 + 3,5	36	12	6	5	10	GN 928.1-5
16	M 8	20 - 30	16	M 5	d₃ / 2 + 4	48	16	8	6	25	GN 928.1-6
20	M 10	30 - 40	20	M 6	d₃ / 2 + 4,8	60	20	10	8	46	GN 928.1-8
25	M 12	40 - 60	25	M 8	d₃ / 2 + 5,6	72	25	12	10	82	GN 928.1-10
30	M 16	60 - 125	30	M 10	d₃ / 2 + 7,9	85	30	16	14	206	GN 928.1-14

Filter combination produces no result.

Specification

Steel
Blackened

Socket cap screw DIN 912
Zinc plated, blue passivated

Application Video trueround

ISO Fundamental Tolerances

RoHS

Accessory

Mounting tools GN 928.1
(Code no. see table)

Information

With the shaft clamping unit "trueround" GN 928, round workpieces from 6 to 125 mm can be rapidly, accurately and economically clamped.

The threaded hole d₅ can be used for attaching a jig or fixture or a fixing screw for holding the clamping unit in an axial position during an assembly operation.

How to order

d₁

GN 928-16
