without Rest Position

GN 617 Indexing Plungers, steel, blackened

Indexing Plungers steel blackened GN 617 thumbnail

Indexing Plungers steel blackened GN 617 sketch

Type

A	With knob, without lock nut
AK	With knob, with lock nut
G	Without lock nut, with threaded rod
GK	With lock nut, with lock nut

Show filter

d₁ Plunger -0,02/-0,05 Bore H7	d₂	d₃	d₄	e	l₁ ≈	l₂	l₃	l₄	l₅ min.	l₆	l₇	A/F	Spring load in N ≈ initial	end

5	M 10 x 1	21	M 5	13,8	45	5	17	5	15	6	4,5	12	7	17
6	M 12 x 1,5	25	M 6	16,2	54,5	6	20	6	17	10	8	14	9	24
8	M 16 x 1,5	31	M 8	21,9	69	8	26	8	23	12	10	19	11	30
10	M 20 x 1,5	31	M 8	25,4	80	10	33	10	30	12	12	22	19	45

Filter combination produces no result.

Specification

Steel

Blackened
Plunger pin hardened

Knob

Plastic (Polyamide PA)
Black, matte finish
Not removable

Load Rating Information

ISO Fundamental Tolerances

Plastic Characteristics

Metric ISO Thread DIN 13

Metric ISO fine thread DIN 13

RoHS

On request

With inch threads

Information

Type G or GK of the indexing plungers GN 617 have been designed for applications where the indexing plunger is not operated with the standard knob.

The indexing plungers are designed such that the plunger set in the end position (pressure spring is "on block") can also absorb axial forces. For applications in which these forces are substantially above the tensile force applied by the operator (Type G), GN 817 indexing plungers are to be preferred.
