with Clamping Hub

GN 2244 Bellows Couplings

Bore code

B	Without keyway

Show filter

d₁	d₂ - d₃ H8 recommended shaft tolerance h7

19	5-5	5-6	5-8	6-6	6-8	8-8
27	6-6	6-8	6-10	8-8	8-10	10-10
32	10-10	10-12	10-14	12-12	12-14	14-14
40	12-12	12-15	12-19	15-15	15-19	19-19

Filter combination produces no result.

d₁	d₄	l₁	l₂ recommended shaft insertion depth	l₃	l₄	Tightening torque of the screw in Nm ≈

19	M 2	30	10,5	3	6,8	0,5
27	M 2,5	35	12,5	3,5	10,3	0,9
32	M 3	46	15,5	4,3	12	1,5
40	M 4	51	16	5	15	3,5

Filter combination produces no result.

Specification

Hub
AluminumAL
Anodized, natural color

Bellows
Stainless steelNI
AISI 304

Socket cap screws DIN 912
Steel, blackened

Crimp ring
Brass

temperature resistant up to 120 °C

Highlights - Couplings

ISO Fundamental Tolerances

Stainless Steel Characteristics

RoHS

On request

Bore with keyway

Information

Bellows couplings GN 2244 transmit angle positions and torques with extreme precision and zero backlash. The metal bellows also reliably compensates for shaft misalignments and runout tolerances. The clamping hubs make bellows couplings very easy to install.

They are used in applications where precise position and movement transmission is required, such as in the servo drive systems of machine tools and in industrial robots.
