Plastic, Bushing / Retracting Mechanism Steel
GN 522.3 Handwheels with Retractable Handle
ELESA original design VRTP+IR
Bore code
| B | Without keyway |
| K | With keyway |
Type
| R | With revolving retractable handle |
| d2H7 Bore | d3 | d4 | d5 | b | l1 | l2 | l3 | r | Ø Handle | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 80 | 8 | 10 | 18 | 20,5 | 25 | 18 | 17 | 35 | 45 | 29 | 15,5 |
| 100 | 10 | 12 | 18 | 20,5 | 25,5 | 20 | 17 | 37 | 60 | 37 | 18 |
| 125 | 12 | 14 | 22 | 26 | 31 | 22 | 22 | 44 | 65 | 48 | 22 |
| 160 | 14 | 16 | 26 | 31 | 40 | 25 | 27 | 51 | 73 | 65 | 24 |
| 200 | 16 | 20 | 30 | 36 | 48,5 | 28 | 34 | 61 | 80 | 84 | 24 |
| 250 | 20 | 24 | 35 | 44 | 58 | 32 | 38 | 69 | 90 | 105 | 25 |
| 300 | 20 | 26 | 40 | 52 | 66 | 35,5 | 43 | 78 | 90 | 123 | 25 |
| 375* | 26 | - | 35 | 70 | 81 | 39 | 43 | 87 | 90 | 160 | 25 |
Filter combination produces no result.
** not available from stock, requires a minimum order quantity
Specification
Plastic
Technopolymer (Polypropylene PP)
Hub bushing
Steel, blackened
Retractable handle (Polyamide PA)
RoHS
Technopolymer (Polypropylene PP)
- Reinforced, shock-resistant
- Temperature resistant up to 80 °C
- Black, matte finish
Hub bushing
Steel, blackened
Retractable handle (Polyamide PA)
- Plastic, Technopolymer
Black, matte finish - Retracting mechanism
Steel, blackened
RoHS
Information
Elegant design and ergonomic requirements are realised for the handwheels with retractable handle GN 522.3.
When the handle is required in an operating position it is firmly anchored.
To fold it in, it has to be pulled out of the arrest position parallel to the shaft.
A pressure spring will hold the handle in either rest position.
| How to order |
| ||||||||
GN 522.3-200-B20-R |
