Threaded Stud Steel, Zinc Plated / Foot Plastic with Two Mounting Holes

GN 345 Leveling Feet

ELESA original design LV.F Info

Type

A	without nut, without rubber pad
B	with nut, without rubber pad
AG	without nut, with rubber pad
BG	with nut, with rubber pad

Show filter

d₁	d₂	l₁				l₂	l₃	l₄	d₃	k	A/F	Ball Ø	Static load in kN (see information)

80	M 8	43	68	-	-	33	23	24	8,5	54	14	14	16
80	M 10	43	68	98	-	33	23	24	8,5	54	14	14	16
80	M 12	43	68	98	-	33	23	24	8,5	54	14	14	16
80	M 14	68	98	148	-	33	23	24	8,5	54	14	14	16
80	M 16	68	108	148	168	33	23	24	8,5	54	16	14	16
80	M 16	58	98	138	158	43	23	24	8,5	54	24	24	18
80	M 20	98	138	158	198	43	23	24	8,5	54	24	24	18
80	M 24	98	138	158	198	43	23	24	8,5	54	24	24	18
100	M 8	43	68	-	-	33	23	24	12,5	70	14	14	18
100	M 10	43	68	98	-	33	23	24	12,5	70	14	14	18
100	M 12	43	68	98	-	33	23	24	12,5	70	14	14	18
100	M 14	68	98	148	-	33	23	24	12,5	70	14	14	18
100	M 16	68	108	148	168	33	23	24	12,5	70	16	14	18
100	M 16	58	98	138	158	43	23	24	12,5	70	24	24	25
100	M 20	98	138	158	198	43	23	24	12,5	70	24	24	25
100	M 24	98	138	158	198	43	23	24	12,5	70	24	24	25
125	M 20	98	138	158	198	67	23	46	12,5	95	24	24	28
125	M 16	58	98	138	158	67	23	46	12,5	95	24	24	28
125	M 24	98	138	158	198	67	23	46	12,5	95	24	24	28

Filter combination produces no result.

Specification

Foot
Plastic Technopolymer (Polyamide PA)

Glass fiber reinforced
Black, matte finish
Temperature resistant up to 100 °C

Threaded stud
Steel zinc plated, blue passivated

Property class 5.8

Hexagon nut ISO 4032
Steel zinc plated, blue passivated

Rubber underlay (NBR)
70 Shore A, black

Stainless Steel Characteristics

Elastomer Characteristics

Plastic Characteristics

RoHS

Information

Leveling feet GN 345 are capable of withstanding high static loads through the use of a high density plastic material coupled with a design which distributes the load over a larger area.

The values given in the table regarding the static load capacity serve as a guide line only and if these are exceeded serious permanent deformation or breakage of the plastic socket could occur.

The above values have been arrived at by a series of tests whereby a limited number of leveling feet were subjected for a limited time to a vertical static load to the feet.

The details relating to the load bearing capacity are non-binding recommended values and rule out any liability. They constitute no general warranty of quality and condition. The user must determine from case to case whether a product is suitable for the intended use.

The fixing holes are closed by a thin plastic layer, which may be easily punctured.

Leveling feet GN 345 are supplied assembled, but are removable.
