with Full Extension, Load Capacity up to 480 N

GN 1450 Stainless Steel Telescopic Slides

Stainless Steel Telescopic Slides GN 1450 thumbnail

Stainless Steel Telescopic Slides GN 1450 sketch

Type

F	With rubber stop, locking device in back, detach function

Identification no.

1	Fastening using through-holes

Show filter

l₁	l₂ +3/-3 Stroke	l₃	F_s per pair in N at 10,000 cycles	at 50,000 cycles

300	300	600	430	310
350	350	700	450	330
400	400	800	480	360
450	450	900	480	360
500	500	1000	450	330
550	550	1100	430	310
600	600	1200	410	310

Filter combination produces no result.

Specification

Slide profile and bearings
Stainless steelNI AISI 304

Ball cage of outer slide
Plastic

Ball cage of inner slide
Stainless steel AISI 304

Ruber stop and detach function
Plastic / Elastomer

Lubricant
Roller bearing grease, FDA-compliant

Operating temperature -20 °C to 100 °C

Telescopic Slides - Application Video

Mounting holes to GN 1440

Telescopic Slides - Highlights

Telescopic Slides - General Notes and Overview of Types

Telescopic Slides - Mounting and Technical information

Telescopic Slides - Component Options and Fastening Options

Stainless Steel Characteristics

RoHS

On request

Other lengths and hole spacing

Other attachment options

Information

Stainless steel telescopic slides GN 1450 are installed vertically and in pairs. The stroke reaches ≈ 100 % of the nominal length l₁ (full extension).

The telescopic slides are delivered in pairs. They can be installed on the extension on either the left or right side due to the mechanics. All mounting holes are easy to reach through auxiliary holes. Only the mounting holes are shown, but other production-related holes may be present.
