for Serrated Locking Plates GN 187.4 / GN 189, Locking Plates GN 187.5
GN 187.2 Stainless Steel Thrust Springs
| d | Max. spring load in N ≈ | For serrated locking plates GN 187.4 / GN 189 - d0 | For locking plates GN 187.5 - d0 |
|---|---|---|---|
| 15 | 20 | 22 | - |
| 18 | 35 | 27 | 27 |
| 23 | 55 | 32 | 32 |
| 29 | 45 | 40 | 40 |
Filter combination produces no result.
Specification
Information
Stainless steel thrust springs GN 187.2 are placed between serrated locking plates GN 187.4 or GN 189 and locking plates GN 187.5 and ensure that the locking plates separate reliably when removed.
| How to order |
| ||
GN 187.2-18 |
