Plastic, for GN 649 to be Mounted to Round Tubes
GN 649.1 Adapter
ELESA original design APC.
| d Tube-Ø from - up to | Code No. |
|---|---|
| 30-34 | GN 649.1-30-34 |
| 40-43 | GN 649.1-40-43 |
| 48-52 | GN 649.1-48-52 |
Filter combination produces no result.
Specification
Plastic
Technopolymer (Polyamide PA)
Flat socket cap screw DIN 7984-M6
Steel
Zinc plated, blue passivated
Blind rivet nut M6
Steel
Zinc plated, blue passivated
RoHS
Technopolymer (Polyamide PA)
- Glass fiber reinforced
- Gray, RAL 7042, matte finish
- Temperature resistant up to 80 °C
Flat socket cap screw DIN 7984-M6
Steel
Zinc plated, blue passivated
Blind rivet nut M6
Steel
Zinc plated, blue passivated
RoHS
Information
Adapter 649.1 allow panel support clamps GN 649 to be mounted to round tubes.
Mounting the M6 blind rivet nut requires a commercial blind rivet nut pliers or a setting tool.
The blind rivet nut and the flat socket cap screw DIN 7984-M6 are included parts of the order.
