for Aluminum Profiles / Panel Elements
GN 2291 Hinge Wings
Type
| AF | Exterior hinge wing |
| AN | Exterior hinge wing, with guide step |
| IF | Interior hinge wing |
| IN | Interior hinge wing, with guide step |
Coding
| A | Without bores |
| C | With countersunk holes |
| l1 Type AF Type AN | Type IF Type IN | l2 | d1 | d2 | d3 | l3 | l4 | m1 Type AF / AN | Type IF / IN | m2 | m3 | m4 | n -0,3 | s1 | s2 | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 43 | 50 | 40 | 80 | 250* | 400* | 6,6 | 14 | 8 | 36 | 43 | 20,4 | 27,5 | 50 | 50 | 150 | 8 | 3,5 | 6,5 |
Filter combination produces no result.
*only available in types AF / IF
Specification
Accessory
Bolt Sets GN 2290On request
Other lengths and hole spacings
Other finishes
Other finishes
Information
Hinge wings GN 2291 can be combined with bolt sets GN 2290 into individualized hinge versions.
As of a hinge wing length of l2 ≥ 250 mm, individual lengths can be realized by shortening the hinge wing given the greater hole spacings.
| How to order |
| ||||||||||
GN 2291-43-80-AF-A-EL |
