with Electrical Switching Function, Plug Connection
GN 628.4 Cabinet U-Handles, plastic
ELESA original design EBR-SW
Type
| SL | Plug on the side, left |
| SR | Plug on the side, right |
| SU | Plug on the bottom |
| l1 ±0,5 | d1 | d2 | h1 | h2 | l2 | l3 | s |
|---|---|---|---|---|---|---|---|
| 132 | 28 | 8,5 | 44 | 20 | 160 | 89 | 8,5 |
Filter combination produces no result.
Specification
Plastic
Technoplymer (Polyamide PA)
Cover cap
Plastic
Black-gray, matte
RoHS
Technoplymer (Polyamide PA)
- Glass fiber reinforced
- Temperature resistant up to 80 °C
- Black-gray, matte
Similar to RAL 7021
Cover cap
Plastic
Black-gray, matte
RoHS
Accessory
Cables with connector coupling GN 330Information
Cabinet U-handles GN 628.4 are equipped with a pushbutton which operates a make / break contact, for instance to send an electric pulse to switch off a machine.
The cabinet U-handle also houses a red LED which sends an electric signal to the operator to visually indicate a change in machine status.
The cabinet U-handle is therefore a functional and highly compact unit which matches the design of the Ergostyle® product family.
The cover caps are supplied loose.
| How to order |
| ||||
GN 628.4-132-SU |
RoHS compliant:
-
-
Weight:
-
-
