GN 782
Form
| KI | |
| KS |
Kennziffer
| 1 | |
| 2 |
| d2 | d3 | d4 | l1 | l2 | l3 | l4 | l5 | l6 | l7 | sw1 | sw2 | x16 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M 6 | 17 | 8,5 | 10 | 8 | 11 | 20 | 25 | 16,8 | 16 | 15 | 7 | 15 |
| M 8 | 19 | 11 | 12 | 10 | 125 | 23 | 29,5 | 19,5 | 18 | 17 | 9 | 20 |
| M 10 | 21 | 13 | 15 | 12 | 14 | 26 | 33,5 | 23,5 | 20 | 19 | 11 | 35 |
| M 12 | 28 | 16 | 14 | 15 | 20 | 34 | 44 | 27,7 | 28 | 21 | 14 | 45 |
Filter combination produces no result.
Specification
RoHS
Information
| How to order |
| ||||||
782-M10-KI-1 |
RoHS compliant:
-
-
Weight:
-
-
PDF not available
