GN 237 Stainless Steel Hinges
Form
| A | 2x2 bores for countersunk screws |
| C | 2x2 threaded studs |
| l1 NI / A4 Type A | NI Type C | l2 | d1 | d2 | d3 | h1 | h2 | h3 | h4 +0,5 | l3 | l4 | m1 | m2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 30 | - | 30 | - | 4,3 | 3 | 7,5 | 4 | 4,3 | 8,6 | 10,7 | - | 18 | 18 |
| 40 | 40 | 40 | M 5 | 5,3 | 4 | 9 | 5 | 5,5 | 11 | 16 | 11 | 25 | 25 |
| 50 | 50 | 50 | M 6 | 6,4 | 6 | 11,5 | 6 | 6,5 | 13 | 21 | 13 | 30 | 30 |
| 60 | 60 | 60 | M 8 | 8,3 | 8 | 15 | 8 | 8,5 | 17 | 26 | 17 | 36 | 36 |
Filter combination produces no result.
Specification
Stainless steel
Pin
Stainless steel AISI 316Ti (A4)
Threaded stud (Type C)
Stainless steel AISI CF-8
casted „in one piece"
RoHS
- AISI CF-8 NI
- German Material No. 1.4408 A4
- Matte shot-blastedGS
Pin
Stainless steel AISI 316Ti (A4)
Threaded stud (Type C)
Stainless steel AISI CF-8
casted „in one piece"
RoHS
Information
Stainless steel hinges GN 237 are characterized by their compact and stable design. The various material and surface choices in combination with two mounting types enable very specific applications.
| How to order |
| ||||||||||
GN 237-A4-40-40-A-GS |
