Plastic
GN 239.7 Hinges
ELESA original design CFMW.
| l1 | l2 | h1 | h2 | h3 | m1 | m2 |
|---|---|---|---|---|---|---|
| 60 | 70 | 25 | 15 | 15 | 42 | 50 |
| 60 +1 | 110 | 25 | 15 | 15 | 42 | 91 |
Filter combination produces no result.
Specification
Housing
Plastic (Polyamide PA-HP)
Pin and mounting bushings
Plastic (Polyamide PA)
Plastic Characteristics
Overview to appropriate standards of the assembly sets GN 965
Overview to appropriate standards of the assembly sets GN 968
List of Hinge Types
RoHS
Plastic (Polyamide PA-HP)
- Glass fiber reinforced
- Black, matte finish
- Temperature resistant up to 100 °C
Pin and mounting bushings
Plastic (Polyamide PA)
- Glass fiber reinforced
- Black, matte finish
- Temperature resistant up to 100 °C
Plastic Characteristics
Overview to appropriate standards of the assembly sets GN 965
Overview to appropriate standards of the assembly sets GN 968
List of Hinge Types
RoHS
On request
Housing in gray, RAL 7040
Information
The GN 239.7 hinges without switch have the same design like hinges GN 239.6 and serve as auxiliary hinge, e.g. for large doors requiring several hinges.
see also...
| How to order |
| ||||
GN 239.7-60-70 |
RoHS compliant:
-
-
Weight:
-
-
