as Device Bases, Sliding Guides, Screw Covers
GN 338 Disks with Cover Cap, Steel, zinc plated, plastic
Type
| KS | Cover cap, gliding |
| KR | Cover cap, non-gliding |
| d1 | d2 | h1 | h2 | h3 |
|---|---|---|---|---|
| 16 | 3,2 | 5 | 1 | 3,7 |
| 20 | 4,3 | 5 | 1 | 3,7 |
| 25 | 4,3 | 5,7 | 1 | 4 |
| 32 | 5,3 | 6,7 | 1 | 5 |
Filter combination produces no result.
Specification
Steel
Zinc plated, blue passivated
Cover caps
RoHS
Zinc plated, blue passivated
Cover caps
- Type: KS
Polyacetal (POM)
Cream white RAL 9001 - Type: KR
Elastomer (TPE)
≈ 75 Shore A
Black
RoHS
On request
Cover cap in other colors
Information
The application examples given above demonstrate the versatility of disks with cover cap GN 338.
Removal of the cover can be done by inserting a screwdriver in the gap on the edge.
| How to order |
| ||||
GN 338-25-KS |
