GN 6336.4 Star Knobs, with threaded stud steel

Show filter

d₁	d₂	Length l ≈ Material ST						d₃	h₁	h₂

32	M 6	16	20	25	30	35	45	12	20	9
40	M 8	16	20	25	30	40	55	14	25	12
50	M 10	25	30	35	45	55	-	18	32	15
63	M 12	30	35	40	50	60	-	20	40	19
80*	M 16	30	40	50	60	70	-	25	50	23

Filter combination produces no result.

* not available in version ZB

Specification

Knob
Cast ironSG
Fettled and tumbled

Threaded stud
Steel blackened

The threaded stud is screwed in and secured by a cross-dowel

RoHS

How to order

GN 6336.4-SG-63-M12-50

RoHS compliant: Info

Weight:
