without Thread, Ball with Friction Bearing
GN 614.8 Stainless Steel Spring Plungers
| d1 ±0,04 | d2 | Length l | w compression | Spring load in N ≈ initial | end |
|---|---|---|---|---|---|
| 4 | 2 | 11 | 0,5 | 4,8 | 6,8 |
| 5 | 2,5 | 13 | 0,7 | 6,3 | 10 |
| 6 | 3,5 | 15 | 0,95 | 16 | 24 |
| 8 | 4,5 | 18 | 1,5 | 18,8 | 31,7 |
| 10 | 6,5 | 20 | 2,3 | 26 | 49 |
| 12 | 8,5 | 22 | 3,1 | 38 | 68 |
Filter combination produces no result.
Specification
Housing
Stainless steelNI AISI 303
Ball
Stainless steel AISI 420C
Hardened
Pressure spring
Stainless steel AISI 631
Friction bearing
RoHS
Stainless steelNI AISI 303
Ball
Stainless steel AISI 420C
Hardened
Pressure spring
Stainless steel AISI 631
Friction bearing
- Plastic
- Temperature resistant up to 90 °C
RoHS
Information
Stainless steel spring plungers GN 614.8 are used for locking as well as for pressure and hold-off functions.
The ball is mounted in a plastic shell so as to be freely movable, which enables rolling and therefor generally optimizes the locking characteristics. Above all, this reduces wear on the counter piece.
A further characteristic of these plungers is that the plastic bearing acts as an electrical insulator.
For the mounting hole, tolerance d1 F8 is recommended for joined fitting and d1 H9 for press fitting.
